Quick Details

  • Place of Origin: Hebei, China (Mainland)
  • Brand Name: XUNQIANG
  • Model Number: welded wire mesh panel
  • Material: Galvanized Iron Wire, Galvanized Iron Wire
  • Type: Welded Mesh
  • Application: Cages
  • Hole Shape: Square
  • Aperture: 50*50
  • Wire Gauge: 2.0-6.0mm
  • application: Construction Wire
  • Certification: BV,SGS,ISO9001
  • Surface treatment: Galvanized and PVC coated
  • Strength Grade: Min 500MPa
  • Standard: ANSI4671,BS 4483:2005
  • Opening: 50*50 - 200*200
  • Width: Within 2.2m, according to your requirements
  • Main market: South Pacific;Oceania;Mid-East;Southeast Asia:mid-Asia:africa,etc
  • Mesh: 1/2 inch --200mm , according to your requirements
  • Package: Exporting package ,or according to your requirements

Packaging & Delivery

Packaging Details: packed with plastic film and then waterproof paper
packed in wooden pallets or wooden box
Delivery Detail: 7-10 days after receiving advance payment

HeBei XunQiang Metal Wire Mesh Co., Ltd.

New products 2016 Hot Sale galvanized welded wire mesh panel

Product Description

 Dear friend,take you into the welded wire mesh panel ......

Assortments: welded wire mesh ,Welded wire mesh panel, electric galvanized welded wire mesh panel, hot  mesh, construction mesh, steel bar welded wire mesh, welded wire mesh for brick, welded wire mesh for reinforced concrete, welded wire mesh for floor heating

MaterialLow carton steel wire, stainless steel wire, iron wire, Galvanized steel wire, PVC coated iron wire in blue ,gdipped galvanized welded wire mesh, pvc coated wire mesh, heavy welded wire mesh, stainless steel welded wirereen ,yellow and other colours.

FeaturesSmooth and trim mesh surface, sold and uniform structure and superior integral performance, it won’t loosen even subject to local cutting or pressure, it has the characteristics of corrosion-resisting and oxidation-resisting.

We may produce the diameter, mesh, width, length and width as the customers' required.

Packing: Moist-proof paper, shrink bag, loose packing, pallet of special packing can be arranged upon request

Use: Galvanized welded wire mesh, PVC coated welded wire mesh for garden, feeding agriculture, fishing, poultry, mine field, lawn cultivation, profession's guard, decorate machine protection. Special welded wire mesh ,(Heavy)welded wire mesh panel service as fencing mesh for transportation industry, construction a agriculture.

We also have other production lines such as link chain fence, hexagonal wire mesh, fiberglass wire mesh, galvanized wire, black annealed



Our factory has the advanced machine and so you do not worry the quality.We can send you the sample for free. >>>Contact us

opening

Wire diameter(BWG)

In inch

In metric unit (mm)

1/4”X1/4”

6.4mmX6.4mm

22,23,24

3/8”X3/8”

10.6mmX10.6mm

19,20,21,22

1/2”X1/2”

12.7mmX12.7mm

16,17,18,19,20,21,22,23

5/8”X5/8”

16mmX16mm

18,19,20,21

3/4”X3/4”

19.1mmX19.1mm

16,17,18,19,20,21

1”X1/2”

25.4mmX12.7mm

16,17,18,19,20,21

1-1/2”X1-1/2”

38mmX38mm

14,15,16,17,18,19

1”X2”

25.4mmX50.8mm

14,15,16

2”X2”

50.8mmX50.8mm

12,13,14,15,16


Product show

 You can tell us the exact specification you need and l can give you the quotationright now. .>>>Contact us







Galvanized Fence Before Welding , Galvanized Fence After Welding



Note: The Corrosion Resistance of Galvanized Fence After Welding is better, not easy to rust.



Specification



Diameter: 0.4-3mm(Roll)   2.0-5.5mm(Sheet/Panel)

Mesh Hole: 1/4"-2"(Roll)     2"-4"(Sheet/Panel)

Mesh Length: 15-30m(Roll) 2-6m(Sheet/Panel)

Mesh Width: 0.7-1.5m(Roll)   <3.0m(Sheet/Panel)



Mesh Size

Wire Diameter

Panel Width & Length

In MM

In Inch

MM

12.7mm

1/2Inch

1.0mm - 2.0mm

3Feet x 6Feet 4Feet x 8Feet 5Feet x 10Feet 1M X 2M 1.5M X 3M 2M X 4M Other panel sizes can also be made according to request

25.4mm

1Inch

1.5mm - 3.5mm

31.8mm

1 1/4Inch

2.0mm - 4.0mm

38.1mm

1 1/2Inch

2.0mm - 5.0mm

50.8mm

2Inch

2.0mm - 6.0mm

76.2mm

3Inch

3.0mm - 7.0mm

101.6mm

4Inch

3.0mm - 8.0mm

127mm

5Inch

4.0mm - 9.0mm

152.4mm

6Inch

4.0mm - 10.0mm









We delivery 3000 panel 2x4 welded wire mesh panel to Egypt



Application

1> Installation and fixing of heating pipes or cables

2> Reinforced concrete construction

3> Protect fencing

4> Animal Cage

5> Welded Stone Cage







Certifications





Our Services



1. Sample service

Samples are free .we can send to you by DHL TNT Fedex UPS within 5-7 days
2. Customized service
Customized service is available for us . we can customized as your design and specification .
3. After-sales service
 Our after-sales service start immediately after signing the contract.
No matter FOB or CIF the price term . we would try our best to find a lowest freight cost for customers' reference.

The third-party inspection always gets real and true data from us and we will send production photos to customers
if there is no inspection.

Do our best to help customer arrange the shipment and customs clearance.

Installation, maintenance and repair instructions with full information.

3-8 years warranty depends to different products.
